IPE300 series engineering VFD Dimension drawings
-339-
bracket. For 380V 01R5 to 0075 VFD models, the keypad mounting bracket is an optional part. For
models of 380V 0090 to 0500 and 660V 22 to 630kW, you can use optional brackets or use the
standard keypad brackets externally.
Installation dimensionsKeypad adapter bracket
103
98
140
115
4-R12
Figure C-3 Keypad mounting bracket (optional) for 380V 01R5 –0500 and 660V 22–630kW models
C.3 VFD structure
Figure C-4 VFD structure
