INVT IPE300 Series User Manual

IPE300 series engineering VFD Function parameter list
-166-
P09 group–– PID control
Function
code
Name
Description
Default
Modify
P09.00
PID reference
source
When frequency command selection
(P00.06, P00. 07) is 7, or channel of voltage
setup (P04.27) is 6, the running mode of
VFD is process PID control.
The function code determines the target
given channel during the PID process.
0: Keypad (P09.01)
1: AI1
2: AI2
3: AI3
4: High-speed pulse HDIA
5: Multi-step running
6: Modbus communication
7: PROFIBUS/CANopen/DeviceNet
communication
8: Ethernet communication
9: High-speed pulse HDIB
10: EtherCat/Profinet communication
11: PLC
12: Reserved
The set target of process PID is a relative
value, for which 100% equals 100% of the
feedback signal of the controlled system.
The system always calculates a related
value (0–100.0%).
0
○
P09.01
PID reference
preset through
keypad
The function code is mandatory when
P09.00=0. The base value of The function
code is the feedback of the system.
Setting range: -100.0%–100.0%
0.0%
○
P09.02
PID feedback
source
Used to select PID feedback channel.
0: AI1
1: AI2
2: AI3
3: High-speed pulse HDIA
4: Modbus communication
5: PROFIBUS/CANopen/DeviceNet
0
○
