INVT IPE300 Series User Manual

IPE300 series engineering VFD Function parameter list
-200-
Function
code
Name
Description
Default
Modify
P18.26
Speed reducing
ratio of the
spindle
Reserved
0.000
●
P18.27
Encoder UVW
sectors
0–7
0
●
P18.28
Encoder PPR
display
0–65535
0
●
P18.29
Angle
compensation
value of SM
-180.0–180.0
0.0
●
P18.30
Reserved
0–65535
P18.31
Z pulse value of
pulse reference
0–65535
0
●
P18.32–P
18.35
Reserved
0–65535
0
●
P19 group––Extension card status viewing
Function
code
Name
Description
Default
Modify
P19.00
Slot 1 status
0–65535
0: No card
1: PLC card
2: I/O card
3: Incremental PG card
4: Incremental PG card with UVW
5: Ethernet
6: DP
7: Bluetooth card
8: Rotary PG card
9: CANopen communication card
10: WIFI card
11: PROFINET communication card
12: Sine-cosine PG card without CD signals
13: Sine-cosine PG card with CD signals
14: Absolute encoder PG card
15: CAN master/slave communication card
16: Modbus communication card
17: EtherCAT communication card
18: BACnet communication card
19: DeviceNet communication card
0
●
P19.01
Slot 2 status
0
●
P19.02
Slot 3 status
0
●
