INVT IPE300 Series User Manual

IPE300 series engineering VFD Basic operation guidelines
-39-
All digits are
blinking
The units place
is blinking
The units place
is blinking
The units place is blinking
The units place is blinking
The units place is blinking
Note: When setting the value, you can press and to modify the value.
+
PRG
ESC
PRG
ESC
PRG
ESC
PRG
ESC
DATA
ENT
DATA
ENT
DATA
ENT
Figure 5-4 Setting a password
5.4.3 Viewing VFD status
The VFD provides group P17 for status viewing. You can enter group P17 for viewing.
All digits are
blinking
The units place
is blinking
The units place is blinking
The units place is blinking
The units place is blinking
Note: When setting the value, you can press and to modify the value.
+
DATA
ENT
DATA
ENT
DATA
ENT
PRG
ESC
PRG
ESC
PRG
ESC
PRG
ESC
Figure 5-5 Viewing a parameter
5.5 Basic operation description
5.5.1 What this section describes
This section introduces the function modules inside the VFD.
 Ensure that all terminals have been securely connected.
 Ensure that the motor power matches the VFD power.
5.5.2 Common commissioning procedure
The common commissioning procedure is as follows (taking motor 1 as an example).
