IPE300 series engineering VFD Dimension drawings
-346-
W1
W2
D1
H1 H2
6- ø13.0
W2
Figure C-17 Wall-mounting drawing for the 660V 250–355kW models
VFD model
Outer dimension (mm)
Installation dimension (mm)
Hole diameter
(mm)
Fixing
screw
W1
H1
D1
W2
H2
250kW–355kW
680
960
380
230
926
13
M12
C.5.2 Flange installation dimensions
W1
H1
D1
W2
H2
98.0
D2
W2
W3W4
H4
H2
H3
Figure C-18 Flange installation diagram for 660V 22–132kW models
VFD model
Outer dimension
(mm)
Installation dimension (mm)
Hole
diameter
(mm)
Fixing
screw
W1
H1
D1
W2
H2
D2
W3
H3
W4
H4
22kW–45kW
270
555
325
130
540
167
261
516
65.5
17
7
M6
55kW–132kW
325
680
363
200
661
182
317
626
58.5
23
9.5
M8
