INVT IPE300 Series User Manual

IPE300 series engineering VFD Function parameter list
-192-
P16 group––Communication extension card 2 functions
Function
code
Name
Description
Default
Modify
P16.00–P
16.23
See the operation manual of GD350 communication extension card for details
P16.24
Time to identify
extension card in
card slot 1
0.0–600.0s
The value 0.0 indicates that identification fault will
not be detected.
0.0s
○
P16.25
Time to identify
extension card in
card slot 2
0.0–600.0s
The value 0.0 indicates that identification fault will
not be detected.
0.0s
○
P16.26
Time to identify
extension card in
card slot 3
0.0–600.0s
The value 0.0 indicates that identification fault will
not be detected.
0.0s
○
P16.27
Communication
timeout period of
card at slot 1
0.0–600.0s
The value 0.0 indicates offline fault will not be
detected.
0.0s
○
P16.28
Communication
timeout period of
card at slot 2
0.0–600.0s
The value 0.0 indicates offline fault will not be
detected.
0.0s
○
P16.29
Communication
timeout period of
card at slot 3
0.0–600.0s
The value 0.0 indicates offline fault will not be
detected.
0.0s
○
P16.30–P
16.69
See the operation manual of GD350 communication extension card for details
P17 group––Monitoring parameter group
Function
code
Name
Description
Default
Modify
P17.00
Set frequency
Displays the present set frequency of the VFD.
Range: 0.00Hz–P00.03
50.00Hz
●
P17.01
Output frequency
Displays the present output frequency of the
VFD.
Range: 0.00Hz–P00.03
0.00Hz
●
P17.02
Ramp reference
frequency
Displays the present ramp reference frequency
of the VFD.
Range: 0.00Hz–P00.03
0.00Hz
●
P17.03
Output voltage
Displays the present output voltage of the VFD.
Range: 0–1200V
0V
●
