INVT IPE300 Series User Manual

IPE300 series engineering VFD Function parameter list
-186-
Function
code
Name
Description
Default
Modify
P14.06
Communication
processing
action
0x00–0x11
Ones place:
0: Respond to write operations
1: Not respond to write operations
Tens place:
0: Communication password protection is
invalid.
1: Communication password protection is
valid.
0x00
○
P14.07–
P14.24
Reserved
0–65535
0
●
P15 group––Communication extension card 1 functions
Function
code
Name
Description
Default
Modify
P15.00
Extension card
type
0: Profibus_Dp
1: CANOPN
2: DeviceNET
3: BACnet_MSTP
4: Reserved
0
◎
P15.01
Module address
0-127
2
◎
P15.02
Received PZD2
Value after the calculation with
P91.00–P91.21
0: Disable
1: Set frequency (0–Fmax (Unit: 0.01Hz))
2: PID reference (0–1000, in which 1000
corresponds to 100.0%)
3: PID feedback (0–1000, in which 1000
corresponds to 100.0%)
4: Torque setting (-3000–+3000, in which
1000 corresponds to 100.0% of the motor
rated current)
5: Setting of the upper limit of forward
running frequency (0–Fmax, unit: 0.01 Hz)
6: Setting of the upper limit of reverse
running frequency (0–Fmax, unit: 0.01 Hz)
7: Upper limit of the electromotive torque
(0–3000, in which 1000 corresponds to
0
○
P15.03
Received PZD3
0
○
P15.04
Received PZD4
0
○
P15.05
Received PZD5
0
○
P15.06
Received PZD6
0
○
P15.07
Received PZD7
0
○
P15.08
Received PZD8
0
○
P15.09
Received PZD9
0
○
P15.10
Received PZD10
0
○
P15.11
Received PZD11
0
○
P15.12
Received PZD12
0
○
