IPE300 series engineering VFD Optional peripheral accessories
-360-
Note:
1. The rated input voltage drop of input reactors is 2%±15%.
2. The current adjustment coefficient on the input side of the VFD is higher than 90% after a DC
reactor is configured.
3. The rated output voltage drop of output reactors is 1%±15%.
4. The preceding table describes external accessories. You need to specify the ones you choose
when purchasing accessories.
D.7 Filters
J10 is not connected in factory for the 380V 0110 and lower VFD models. Connect the J10 packaged
with the manual if the requirements of level C3 need to be met.
J10 is connected in factory for the 380V 0132 and higher VFD models, all of which meet the
requirements of level C3.
Note: Disconnect J10 in the following situations:
1. The EMC filter is applicable to the neutral-grounded grid system. If it is used for the IT grid
system (that is, non-neutral grounded grid system), disconnect J10.
2. If leakage protection occurs during configuration of a residual-current circuit breaker, disconnect
J10.
