INVT IPE300 Series User Manual

IPE300 series engineering VFD Function parameter list
-121-
P02 group––Parameters of motor 1
Function
code
Name
Description
Default
Modify
P02.00
Type of motor 1
0: Asynchronous motor (AM)
1: Synchronous motor (SM)
0
◎
P02.01
Rated power of
AM 1
0.1–3000.0kW
Model
depended
◎
P02.02
Rated frequency
of AM 1
0.01Hz–P00.03 (Max. frequency)
50.00Hz
◎
P02.03
Rated speed of
AM 1
1–36000rpm
Model
depended
◎
P02.04
Rated voltage of
AM 1
0–1200V
Model
depended
◎
P02.05
Rated current of
AM 1
0.8–6000.0A
Model
depended
◎
P02.06
Stator resistance
of AM 1
0.001–65.535Ω
Model
depended
○
P02.07
Rotor resistance
of AM 1
0.001–65.535Ω
Model
depended
○
P02.08
Leakage
inductance of AM
1
0.1–6553.5Mh
Model
depended
○
P02.09
Mutual
inductance of AM
1
0.1–6553.5Mh
Model
depended
○
P02.10
No-load current
of AM 1
0.1–6553.5A
Model
depended
○
P02.11
Magnetic
saturation
coefficient 1 of
iron core of AM 1
0.0–100.0%
80.0%
○
P02.12
Magnetic
saturation
coefficient 2 of
iron core of AM 1
0.0–100.0%
68.0%
○
P02.13
Magnetic
saturation
coefficient 3 of
iron core of AM 1
0.0–100.0%
57.0%
○
