INVT IPE300 Series User Manual

IPE300 series engineering VFD Dimension drawings
-347-
W1
D1
W2 W2
D2
H2H1
W4
W3
W2
W2
H4
H2
H3
Figure C-19 Flange installation diagram for 660V 160–220kW models
VFD model
Outer dimension
(mm)
Installation dimension (mm)
Hole
diameter
(mm)
Fixing
screw
W1
H1
D1
W2
H2
D2
W3
H3
W4
H4
160kW–220kW
500
870
358
180
850
178.5
480
796
60
37
11
M10
C.5.3 Floor installation dimensions
W4
W2
W2
H1
H2
D1
W1
W3
D2
D2
3- ø13.0
6- ø12.0
Figure C-20 Floor installation diagram for 660V 250–355kW models
VFD model
Outer dimension (mm)
Installation dimension
(mm)
Hole
diameter
(mm)
Fixing
screw
W1
H1
D1
W4
W2
W3
H2
D2
250kW–355kW
750
1410
380
680
230
714
1390
150
13/12
M12/M10
