INVT IPE300 Series User Manual

IPE300 series engineering VFD Function parameter list
-199-
Function
code
Name
Description
Default
Modify
P18.12
Encoder Z pulse
angle
Reserved.
Setting range: 0.00–359.99
0.00
●
P18.13
Encoder Z pulse
error times
Reserved.
Range: 0–65535
0
●
P18.14
High-order bit of
encoder pulse
count value
Encoder pulse count value. The count value is
accumulated only if the VFD is powered on.
0–65535
0
●
P18.15
Low-order bit of
encoder pulse
count value
Encoder pulse count value. The count value is
accumulated only if the VFD is powered on.
0–65535
0
●
P18.16
Reserved
0–65535
P18.17
Pulse command
frequency
Pulse command (A2/B2 terminal) is converted
to the set frequency, and it is valid under the
pulse position mode and pulse speed mode.
Range: -3276.8–3276.7Hz
0.00Hz
●
P18.18
Pulse command
feedforward
Pulse command (A2/B2 terminal) is converted
to the set frequency, and it is valid under the
pulse position mode and pulse speed mode.
Range: -3276.8–3276.7Hz
0.00Hz
●
P18.19
Position
regulator output
Position regulator output frequency at position
control
Range: -3276.8–3276.7Hz
0
●
P18.20
Count value of
resolver
Count value of the resolver.
Range: 0–65535
0
●
P18.21
Resolver angle
Pole position angle read by the resolver-type
encoder.
Setting range: 0.00–359.99
0.00
●
P18.22
SM pole angle in
closed loop
Present pole position.
Setting range: 0.00–359.99
0.00
●
P18.23
SW 3
0–65535
0
●
P18.24
High-order bit of
count value of
pulse reference
Pulse command (A2,B2) count value. The
count value is accumulated only if the VFD is
powered on.
0–65535
0
●
P18.25
Low-order bit of
count value of
pulse reference
Pulse command (A2,B2) count value. The
count value is accumulated only if the VFD is
powered on.
0–65535
0
●
