INVT IPE300 Series User Manual

IPE300 series engineering VFD Function parameter list
-180-
Function
code
Name
Description
Default
Modify
P12.06
Stator resistance
of AM 2
0.001–65.535Ω
Model
depended
○
P12.07
Rotor resistance
of AM 2
0.001–65.535Ω
Model
depended
○
P12.08
Leakage
inductance of AM
2
0.1–6553.5mH
Model
depended
○
P12.09
Mutual
inductance of AM
2
0.1–6553.5mH
Model
depended
○
P12.10
No-load current
of AM 2
0.1–6553.5A
Model
depended
○
P12.11
Magnetic
saturation
coefficient 1 of
iron core of AM 2
0.0–100.0%
80%
○
P12.12
Magnetic
saturation
coefficient 2 of
iron core of AM 2
0.0–100.0%
68%
○
P12.13
Magnetic
saturation
coefficient 3 of
iron core of AM 2
0.0–100.0%
57%
○
P12.14
Magnetic
saturation
coefficient 4 of
iron core of AM 2
0.0–100.0%
40%
○
P12.15
Rated power of
SM 2
0.1–3000.0kW
Model
depended
◎
P12.16
Rated frequency
of SM 2
0.01Hz–P00.03 (Max. frequency)
50.00Hz
◎
P12.17
Number of pole
pairs of SM 2
1–128
2
◎
P12.18
Rated voltage of
SM 2
0–1200V
Model
depended
◎
P12.19
Rated current of
SM 2
0.8–6000.0A
Model
depended
◎
