INVT IPE300 Series User Manual

IPE300 series engineering VFD Function parameter list
-197-
Function
code
Name
Description
Default
Modify
P17.55
Present integral
gain
0–10.00
0.0s
●
P17.56
Present
differential time
0–10.00
0.0s
●
P17.57
Reserved
0–65535
0
●
P17.58
Control word 1
0x0000–0xFFFF
DP communication upper computer sends the
value after P90.66 polarity conversion
0
●
P17.59
Status word 1
0x0000–0xFFFF
Value uploaded to upper computer via DP
communication after P90.68 polarity
conversion
0
●
P17.60
Control word 2
0x0000–0xFFFF
DP communication upper computer sends the
value after P90.67 polarity conversion
0
●
P17.61
Status word 2
0x0000–0xFFFF
Value uploaded to upper computer via DP
communication after P90.69 polarity
conversion
0
●
P17.62
Max.
temperature
detection value
0–200.0
Max temperature value during the temperature
detection cycle (P91.56)
0
●
P17.63
AB configuration
type display
0x0000–0xFFFF
Each bit represents whether the configuration
is selected
Bit0: Ctrl/Stat & Ref/Fdbk (2+2bytes)
Bit1: Ctrl/Stat & Ref/Fdbk (2+4bytes)
Bit2: DataLink A (2x2bytes)
Bit3: DataLink A (2x4bytes)
Bit4: DataLink B (2x2bytes)
Bit5: DataLink B (2x4bytes)
Bit6: DataLink C (2x2bytes)
Bit7: DataLink C (2x4bytes)
Bit8: DataLink D (2x2bytes)
Bit9: DataLink D (2x4bytes)
Bit10: Parameter Access
Bit11–Bit15: Reserved
0
●
