INVT IPE300 Series User Manual

IPE300 series engineering VFD Basic operation guidelines
-77-
Function
code
Name
Description
Default
Tens place: HDIB input type
0: HDIB is high-speed pulse input
1: HDIB is digital input
P05.24
AI1 lower limit
0.00V–P05.26
0.00V
P05.25
Corresponding setting of AI1
lower limit
-300.0%–300.0%
0.0%
P05.26
AI1 upper limit
P05.24–10.00V
10.00V
P05.27
Corresponding setting of AI1
upper limit
-300.0%–300.0%
100.0%
P05.28
AI1 input filter time
0.000s–10.000s
0.100s
P05.29
AI2 lower limit
-10.00V–P05.31
-10.00V
P05.30
Corresponding setting of AI2
lower limit
-300.0%–300.0%
-100.0%
P05.31
AI2 middle value 1
P05.29–P05.33
0.00V
P05.32
Corresponding setting of AI2
middle value 1
-100.0%–100.0%
0.0%
P05.33
AI2 middle value 2
P05.31–P05.35
0.00V
P05.34
Corresponding setting of AI2
middle value 2
-300.0%–300.0%
0.0%
P05.35
AI2 upper limit
P05.33–10.00V
10.00V
P05.36
Corresponding setting of AI2
upper limit
-300.0%–300.0%
100.0%
P05.37
AI2 input filter time
0.000s–10.000s
0.100s
P05.38
HDIA high-speed pulse input
function selection
0: Input set through frequency
1: Reserved
2: Input set through encoder, used
together with HDIB
0
P05.39
HDIA lower limit frequency
0.000 kHz–P05.41
0.000kHz
P05.40
Corresponding setting of
HDIA lower limit frequency
-300.0%–300.0%
0.0%
P05.41
HDIA upper limit frequency
P05.39–50.000kHz
50.000kHz
P05.42
Corresponding setting of
HDIA upper limit frequency
-300.0%–300.0%
100.0%
P05.43
HDIA frequency input filter
time
0.000s–10.000s
0.030s
P05.44
HDIB high-speed pulse input
function selection
0: Input set through frequency
1: Reserved
0
