GZD15, WSM TRANSAXLE
2-S3
2. SERVICING SPECIFICATIONS
Item Factory Specification Allowable Limit
Brake Spring Length at Parking Setting length 27 mm
1.06 in.
Regulator Valve Setting pressure 0.5 to 0.6 MPa
5.1 to 6.1
72.5 to 87.0 psi
PTO Clutch Operating pressure 0.98 to 1.08 MPa
10.0 to 11.0
142.3 to 156.6 psi
Check and High Pressure Relief Valve Relief valve setting
pressure
18.5 to 22.5 MPa
189 to 230
2683 to 3263 psi
Maximum Speed at Maximum Engine rpm Wheel rotation 140 to 160 rpm
Motion Control Lever Alignment Gap 0 to 2 mm
0 to 0.08 in.
Space 10 to 20 mm
0.4 to 0.8 in.
19T Bevel Gear to Spiral Bevel Gear Backlash 0.15 to 0.30 mm
0.0059 to 0.0118 in.
0000001619E
