GZD15, WSM GENERAL

G-10

[3] AMERICAN STANDARD SCREWS, BOLTS AND NUTS WITH UNC OR

UNF THREADS

[4] PLUGS

Grade

SAE GR.5 SAE GR.8

Unit

Norminal

Diameter

ft-lbs ft-lbs

5/16 23.1 to 27.8 2.35 to 2.84 17.0 to 20.5 32.5 to 39.3 3.31 to 4.01 24.0 to 29.0

3/8 47.5 to 57.0 4.84 to 5.82 35.0 to 42.0 61.0 to 73.2 6.22 to 7.47 45.0 to 54.0

1/2 108.5 to 130.2 11.07 to 13.29 80.0 to 96.0 149.2 to 179.0 15.22 to 18.27 110.0 to 132.0

9/16 149.2 to 179.0 15.22 to 18.27 110.0 to 132.0 217.0 to 260.4 22.14 to 26.57 160.0 to 192.0

5/8 203.4 to 244.1 20.75 to 24.91 150.0 to 180.0 298.3 to 358.0 30.44 to 36.53 220.0 to 264.0

0000001414E

Shape Size

Material of opponent part

Ordinariness Aluminum

ft-lbs ft-lbs

Tapered

screw

R1/8 12.7 to 21.6 1.3 to 2.2 9.4 to 15.9 12.7 to 19.6 1.3 to 2.0 9.4 to 15.4

R1/4 24.5 to 44.1 2.5 to 4.5 18.1 to 32.5 24.5 to 34.3 2.5 to 3.5 18.1 to 25.4

R3/8 49.0 to 88.3 5.0 to 9.0 36.2 to 65.1 49.0 to 58.8 5.0 to 6.0 36.2 to 43.4

R1/2 58.8 to 107.9 6.0 to 11.0 43.4 to 79.6 58.8 to 78.5 6.0 to 8.0 43.4 to 57.9

Straight

screw

G1/4 24.5 to 34.3 2.5 to 3.5 18.1 to 25.3

G3/8 61.8 to 82.4 6.3 to 8.4 45.6 to 60.8

G1/2 49.0 to 88.3 5.0 to 9.0 36.2 to 65.1

0000001666E
