GZD15, WSM ELECTRICAL SYSTEM
5-S1
1. TROUBLESHOOTING
Symptom Probable Cause Solution
Reference
Page
All Electrical
Equipments Do Not
Operate
A Battery discharged or defective Recharge or replace G-32, G-33
A Battery positive cable disconnected or
improperly connected
Repair or replace 5-S5
A Battery negative cable disconnected or
improperly connected
Repair or replace 5-S5
A Slow blow fuse blown Replace
Fuse Blown
Frequently
A Short-circuited Repair or replace
0000001525E
BATTERY
Battery Discharges
Too Quickly
A Battery defective Replace 5-S5
A Dynamo defective Repair or replace 5-S17
A IC Regulator defective Replace
A Wiring harness disconnected or improperly
connected (between battery positive terminal
and regulator B terminal)
Repair or replace
A Cooling fan belt slipping Adjust tension G-31
0000001526E
STARTING SYSTEM
Symptom Probable Cause Solution
Reference
Page
Starter Motor Does
Not Operate
A Battery discharged or defective Recharge or replace G-32, G-33,
5-S5
A Slow blow fuse blown (30A) Replace G-40
A Safety switch defective Repair or replace 5-S10, S11
A Wiring harness disconnected or improperly
connected (between main switch ST terminal
and safety switches, between safety switches
and starter motor, between battery positive
terminal and starter motor)
Repair or replace
A Starter motor defective Repair or replace 5-S13 to S15
A Main switch defective Replace 5-S6 to S7
