Kubota GZD15 User Manual

GZD15, WSM GENERAL
G-11
6. MAINTENANCE
No.
Period
Item
Indication on hour meter
After
since
Refer-
ence
page
50 100 150 200 250 300 350 400 450 500 550 600
1 Engine oil Change
every
100Hr
G-19
2 Engine oil filter Replace
every
200Hr
G-20
3
Transmission and
Rear axle gear case
(RH and LH) fluid
Change
every
200Hr
G-21
4
Transmission oil
filter
Replace
every
200Hr
G-20
5
Transmission
strainer
Clean
every
200Hr
G-23
6 Front PTO case fluid
Check
every
50Hr
G-29
Change
every
150Hr
G-29
7 Front axle pivot Adjust
every
200Hr
G-24 *2
8 Safety device Check
every
50Hr
G-25
9 Oiling -
every
50Hr
G-28
10
Greasing
(without mower)
-
every
50Hr
G-27
11 Mower gear box oil
Check
every
50Hr
G-26
Change
every
150Hr
G-34
12 Air cleaner element
Clean
every
50Hr
G-26 *1
Replace
every
1 year
G-36
13 Battery condition Check
every
50Hr
G-32
14 Fan belt Adjust
every
100Hr
G-31
15 Parking brake Adjust
every
100Hr
G-31 *2
16 Fuel filter element
Check
every
100Hr
G-30
Replace
every
400Hr
G-36 *2
17 Fuel line
Check
every
100Hr
G-30
Replace
every
2 years
G-39 *2
0000001415E
KiSC issued 04, 2006 A

Kubota GZD15 Specifications

General

Transmission	Hydrostatic
Drive Type	2WD
Engine Type	Diesel
Engine Power	15 HP
Weight	640 kg

Summary

SAFETY INSTRUCTIONS

BEFORE SERVICING AND REPAIRING

Crucial steps to take before commencing any service or repair on the machine.

SAFETY STARTING

Procedures to ensure safe engine starting, preventing potential hazards.

SAFETY WORKING

Guidelines for safe operation and maintenance practices to avoid injury.

AVOID FIRES

Critical safety measures to prevent fire hazards during operation and maintenance.

General Information

2. GENERAL PRECAUTIONS

3. HANDLING PRECAUTIONS FOR ELECTRICAL PARTS AND WIRING

Safety guidelines for managing electrical components and wiring systems.

4. LUBRICANTS, FUEL AND COOLANT

5. TIGHTENING TORQUES

Torque specifications for various fasteners to ensure proper assembly.

6. MAINTENANCE

Scheduled maintenance tasks and intervals for optimal machine performance.

7. CHECK AND MAINTENANCE

Detailed procedures for performing regular checks and maintenance.

ENGINE

1. ENGINE BODY

2. LUBRICATING SYSTEM

Explanation of the engine's oil circulation and lubrication system.

3. COOLING SYSTEM

4. FUEL SYSTEM

TRANSAXLE

2. TRAVELLING SYSTEM

Detailed explanation of the hydrostatic transmission and its operation.

3. PTO SECTION

(9) Brake

Description of the brake system components and their operation.

FRONT AXLE

2. SERVICING SPECIFICATIONS

3. TIGHTENING TORQUES

4. CHECKING, DISASSEMBLING AND SERVICING

Procedures for checking, adjusting, disassembling, and servicing the front axle.

HYDRAULIC SYSTEM

1. HYDRAULIC CIRCUIT

2. HYDRAULIC PUMP

3. HYDRAULIC CONTROL VALVE

Explanation of the hydraulic control valve's operation and spool functions.

4. LIFT CYLINDER

[2] GRASS COLLECTOR LIFT CYLINDER AND GRASS COLLECTOR DUMP CYLINDER

5. MOWER LINKAGE

6. GRASS COLLECTOR CONTROL MECHANISM

MOWER

1. POWER TRANSMISSION

Explanation of how power is transmitted from the transmission to the mower blades.

2. LIFTING MECHANISM

Description of the hydraulic system responsible for lifting and lowering the mower deck.
