GZD15, WSM GENERAL
G-7
4. LUBRICANTS, FUEL AND COOLANT
*Oil amount when the oil level is at the upper of the oil level gauge.
**KUBOTA original transmission hydraulic fluid.
No. Place
Capacity
Lubricants, fuel and coolant
GZD15-LD GZD15-HD
1 Fuel tank
20 L
5.3 U.S.gals.
4.4 lmp.gals.
No. 2-D diesel fuel
No. 1-D diesel fuel if temperature is below
-10 (14 )
2Coolant
Cooling
system
1.4 L
1.5 U.S.qts.
1.2 lmp.qts.
Fresh clean water with anti-freeze
Recovery
tank
0.25 L
0.26 U.S.qts.
0.22 lmp.qts.
3 Engine crankcase
2.1 L
2.2 U.S.qts.
1.8 lmp.qts.
Engine oil: API service classification CD, CE or CF
Below 0 (32 ) : SAE10W, 10W-30 or 10W-40
0 to 25 (32 to 77 ) : SAE20, 10W-30 or 10W-40
Above 25 (77 ) : SAE30, 10W-30 or 10W-40
4
Transmission case and
rear axle gear case
(RH and LH)
10.0 L
2.6 U.S.gals.
2.2 lmp.gals.
KUBOTA UDT or SUPER UDT fluid**5 Mower gear box
0.15 L
0.16 U.S.qts.
0.13 Imp.qts.
6 Front PTO case
0.13 L
0.14 U.S.qts.
0.11 Imp.qts.
0000001410E
