Configuration
7-13
 SHB9300CRV EN 2.0
7.4.4 Freely assignable monitor outputs
Use the monitor outputs X6/62 and X6/63 to output internal signals as voltage signals.
Under C0108 and C0109 the outputs can be adapted to e.g. a measuring device or a slave drive.
Themost important codes areindicated in thesubmenu:AOUT1X6.62orAIN2X6.63(analogoutput
1 (X6.62) or analog output 1 (X6.63))
Change assignment:
1. Select the output to be assigned to another signal (source) (e. g. C0431 for output X6/62) in
thecodelevel.
2. Change to the parameter level using PRG. Select the signal from the list which is to be output
via the monitor output.
3. If necessary, adjust an offset in the hardware under C0109
4. If necessary, the signal gain can be adapted to the hardware under C0108.
5. Repeat 1. to 4. to assign the second output.
