Lenze EVS9324-EK User Manual

Function block library
7-137

SHB9300CRV EN 2.0
7.6.43.1 Enable of the FIXSET1 setpoints
Number of required fixed setpoints Number of the inputs to be assigned
1 at least 1
1 ... 3 at least 2
4 ... 7 at least 3
8 ... 15 4
Decoding table of the binary input signals:
Output signal
FIXSET1-OUT =
1st input
FIXSET1-IN1
Input
FIXSET1-IN2
3rd input
FIXSET1-IN3
4th input
FIXSET1-IN4
FIXSET1-AIN 0 0 0 0
C0560/1 1 0 0 0
C0560/2 0 1 0 0
C0560/3 1 1 0 0
C0560/4 0 0 1 0
C0560/5 1 0 1 0
C0560/6 0 1 1 0
C0560/7 1 1 1 0
C0560/8 0 0 0 1
C0560/9 1 0 0 1
C0560/10 0 1 0 1
C0560/11 1 1 0 1
C0560/12 0 0 1 1
C0560/13 1 0 1 1
C0560/14 0 1 1 1
C0560/15 1 1 1 1
