Technical data
3-1
 SHB9300CRV EN 2.0
3 Technical data
3.1 Features
l Several profiles can be stored
l Cam switch function
l Stretching/compression/offset in X and Y direction
l Virtual master
l Clutch replacement / overload clutch
l Welding bar control
l Integrated oscilloscope function
l Power range: 370 W to 75 kW
– Uniform control module and thus uniform connection for the control cables over the
complete power range.
l Heat sink can be separated
– Cooling is possible outside the control cabinet
(push-through technique or ”cold plate technique”)
l Direct connection of resolver or encoder feedback
– Easy connection because of prefabricated system cables (accessories)
– Connecting cables can be plugged
l Integrated angular controller for driftfree standstill
l Digital synchronization system via digital frequency
– Setpoint transmission without offset and gain errors
– Synchronization of speed and rotor position
–Homingfunction
l User configuration for control functions and input and output signals
– Comprehensive function block library
– High flexibility in the adaptation to the internal control structure of the application
l Integrated automation interface
– Easy extension of the controller functionality
l System bus for the connection of servo inverters and for the extension of input and output
terminals
l Approval of standard devices UL 508, File No. 132659 (listed)
l Approval 9371 BB (BAE) UL 508, File No. 132659 (listed)
