Function block library
7-229

SHB9300CRV EN 2.0
7.6.75.3 Evaluate positive or negative edge
t
t
TRANS1-IN
TRANS1-OUT
C0711
C0711
Fig. 7-190 Evaluation of positive and negative edges (TRANS1)
l
The output TRANSx-OUT is set to HIGH as soon as a HIGH-LOW edge or a LOW-HIGH edge
is sent to the input.
l
After the time set under C0711 or C0716 has elapsed, the output changes again to LOW
unless there is another HIGH-LOW edge or LOW-HIGH edge at the input.
