250H - PERIODIC MAINTENANCE - EVERY 250 HOURS OF SERVICE OR 6 MONTHS
ALSO PERFORM THE DAILY MAINTENANCE.
- CHECK Injection pipes, fuel hoses and the hose clamps ...................................................... 3-28
- CHECK Reduction gearbox impermeability .................................................................. 3-28
- CHECK Impermeability of the front and rear axle differentials ................................................ 3-28
- CHECK Impermeability of the front and rear gear reducers................................................... 3-28
- CHECK Generator (OPTION)................................................................................. 3-28
- CHECK Wheel nut tightening ............................................................................... 3-28
- CHECK Alternator/fan belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-28
- CHECK Tightening of the fixing screws for the oscillating cylinders (OPTION) ................................. 3-28
- CHECK Tightening of the fixing screws for the axles.......................................................... 3-29
- CHECK Locking of the front axle oscillating cylinders (OPTION) .............................................. 3-30
- CHECK Overload alarm ..................................................................................... 3-31
- CHECK Braking ............................................................................................. 3-31
- CHECK Turntable rotation motor oil level.................................................................... 3-32
- CHECK Emergency controls................................................................................. 3-33
- CLEAN Fuel filter cartridge.................................................................................. 3-33
- LUBRICATE Shafts, hubs and cylinder rings ...................................................................... 3-34
- LUBRICATE Telescope........................................................................................... 3-35
- LUBRICATE Crown gear ......................................................................................... 3-35
- RESET Maintenance warning............................................................................... 3-35
Âo
500H - PERIODIC MAINTENANCE - EVERY 500 HOURS OF SERVICE OR 1 YEAR
ALSO PERFORM THE DAILY SERVICE AND THE PERIODIC SERVICE AT 250 HOURS OF SERVICE.
- CHECK Basket fixing screw tightening....................................................................... 3-36
- CHECK Tightening of the fixing screws on the basket rotation cylinder ....................................... 3-36
- CHECK Telescope setting ................................................................................... 3-37
- CHECK Tightening of the fixing screws for the crown gear ................................................... 3-38
- CHECK Tightening of the fixing screws on the turntable rotation motor ...................................... 3-39
- CHECK Counterweight fixing screw tightening .............................................................. 3-40
- CHECK Hydraulic hoses ..................................................................................... 3-40
- REPLACE Alternator/fan belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-41
- REPLACE Fuel pre-filter from machine no. 905990 ............................................................... 3-41
- REPLACE Fuel filter cartridge.................................................................................. 3-42
- REPLACE Engine oil........................................................................................... 3-43
- REPLACE Engine oil filter...................................................................................... 3-43
- REPLACE Dry air filter cartridge ............................................................................... 3-44
- REPLACE Turntable rotation motor oil ......................................................................... 3-45
- REPLACE Hydraulic pressure filter cartridge ................................................................... 3-46
- REPLACE Hydrostatic transmission filter cartridge ............................................................. 3-46
- RESET Maintenance warning............................................................................... 3-46
