Mindray DC-8 EXP Service Manual

11-2 System Diagnosis and Support
11.1.2 The Status Indicator of the Power on the IO Rear
Board
Status indicators
Icon
Status definition and indicators
Digital board power
supply
D+12V status indicators
12
Power on, and indicator is on (green), which indicates
D+12V output of the main unit box power module is normal.
Digital board power
supply
D+5V status indicators
5
Power on, and indicator is on (green), which indicates
D+5V output of the main unit box power module is normal.
Digital board power
supplyD+3V3 status
indicators
3.3
Power on, and indicator is on (green), which indicates
D+3V3 output of the main unit box power module is normal.
11.1.3 Monitor Status Indicator
Status
indicators
Icon
Status definition and indicators
Monitor status
Indicator
At the lower right
corner of the monitor
The indicator is green, normally display
The indicator is orange, no video signal input, there
displays “No Signal”, 15s after been powered.
The indicator blinks orange, malfunction in the inverter.
11.1.4 The Status of Whole Machine
Status of
whole
machine
Status definition
and indicators
To enter
To exit
Scanning
status
The Power-on status
indicator turns on
green; The [Freeze]
key is white or light
off.
Entering or exiting the scanning status by the [Freeze] key
Freezing
status
The Power-on status
indicator turns on
green, and the
[Freeze] key is
orange
Entering or exiting the freezing status by the [Freeze] key
Standby
status
The standby indicator
blinks in orange.
1. Press the power button for a short
time, and then the system enters into
the standby status by choosing from
the status popped on the screen.
2. If there is no operation for the time
set at first, the system would enter
The system
restores to the
freeze status after
restarting by
pressing the power
button for a short
