Mindray DC-8 EXP Service Manual

11-8 System Diagnosis and Support
11.3.1 Battery Alarm
11.3.2 The Voltage of System Power Alarm
11.3.3 Temperature Alarm
Alarm Tips
LOG Record
Measure
Battery communication
fails The battery
capacity displayed is not
correct or the current
battery can’t be used
*** Battery I2C error
Check the battery connection
or replace the battery
None
*** Battery I2C error, Shutdown
State
Check the battery connection or
replace the battery
The battery will be out of
power, please replace
quickly!
*** battery cycle is 301, please
change the battery
Replace the battery
Battery is abnormal,
abnormally discharge.
*** battery break
Replace the battery
Alarming tips
LOG record
Measure
The real-time
battery will be
out of power,
please replace
quickly!
*** System Monitor: Power supply
alert! [XXX], Current voltage: [VVV]
V, Limit voltage:[LLL]~[HHH]V
Replace the button battery
none
*** System Monitor: Power supply
alert! [XXX], Current voltage: [VVV]
V, Limit voltage: [LLL]-[HHH]V.
[XXX] represents voltage name,
[VVV] represents the current value,
and [LLL]-[HHH] represents the
lower and upper limits.
The voltage names respectively are:
Back-end power supply: D+12V,
D+5V, D+3V3, D+2V5, D+1V8,
D+1V2, D-5V, D-12V
Front-end power supply: A+5V7,
A+4V, A+3V3, A+2V5, A+1V8,
A-12V, A-5V7, A+19V
1. If one of the power is abnormal
(over-low or over-high) in the
front-end power supply, try to change
the front-end power board.
2. If one of the powers is zero in the
front-end power supply, refer to the
table in 4.8.5; try to change the
corresponding board in front-end.
3. If power in back-end (D+12V, D+5V,
D+3V3, D-5V, D-12V) is over-low or
over-high, try to change the back-end
power board.
4. If power in back-end (D+2V5, D+1V8,
and D+ 1V2) is over-low or over-high,
try to change the digital board.
