Mindray DC-8 EXP Service Manual

Function and Performance Checking Method 5-5
5.4.1 Checking Flow
Check each imaging mode
Check the measurements
Check in cine mode
Check the probe application
Image & video management
Record and save the exam
5.4.2 Content
5.4.2.1 Imaging Modes
1. B mode
 In B Mode scanning, the image parameter area in the upper left corner of the screen will
display the real-time parameter values as follows:
Parameter
F
D
G
FR
DR
iClear
iBeam
iTouch
Zoom
Meaning
Frequency
Depth
Gain
Frame Rate
Dynamic Range
Display when the function is turned on.
 Parameters that can be adjusted to optimize the B Mode image are indicated in the following.
Adjustment
method
Procedure
Standard
Control
Panel
Depth
Changes image display depth----<Depth> deflector rod.
TGC
Manually adjust time gain compensation---- TGC slider.
Gain
Changes the B mode gain---- <B> knob.
iTouch
Image auto-optimization----press <iTouch>.
Focus Position
Changes the focus position----<Focus> deflector rod.
Steer
Changes B steer angle of linear probe----<Steer> deflector rod.
