Mindray DC-8 EXP Service Manual

11-4 System Diagnosis and Support
11.2 Start-up Process of the Whole System
The system is powered on
User screen
Press the power button on the
control panel
Blank screen in the short time
Windows OS startup screen
displays
After blank screen in the short
time, the Doppler startup
screen displays (with progress
bar)
Windows OS starts up
Doppler starts up
After the system is powered on, BIOS
starts up
Power-on status indicator
lights on
HDD indicator starts to
flash
The color of some mode
keys (such as B mode) on
the control panel turns on
orange
1. The control panel
backlight lights on
2. All power status indicators
on IO back panel lights on
3. The fan starts to run
BIOS startup screen displays
Windows login screen
displays
11.2.1 Complete System AC Power on process
Basic operation
Process and Status
Connect system power plug into
main power supply.
AC power indicator on the minor panel is on. Battery indicator is
on (if there is battery). Hard disk indicator and standby indicator
are off.
Press the power button on the
control panel.
Power-on status indicator blinks in a short time and then it is on
normally.
