Mindray DC-8 EXP Service Manual

5-4 Function and Performance Checking Method
Text/graph printer:
Check if the printer and ultrasound system
are correctly connected.
Then check the function of each key.
Press <Print> key, the printer begins to work, no print
deficiency or degradation.
Code bar scanner:
Perform code bar scanning when the
ultrasound system is running normally.
The bar code is correctly displayed on the screen.
5.3.2.6 Check ECG Module
Procedure
Standard
Confirm if the ECG module is
configured, then:
Set [ECG] as “On”.
 ECG trace is displayed; the heart icon is displayed
at the upper right corner of the screen.
 The parameters [Speed], [ECG Gain] can be
adjusted.
 ECG signal can be reviewed correctly.
5.3.2.7 Check I/O Ports
Procedure
Standard
Checking the main I/O ports:
Besides the video/audio ports, USB ports, the
other ports required to be checked including:
VGA/DVI port;
Connect external VGA/LCD monitor (with
resolution supporting 1680*1050)
Network port;
Other USB ports.
 The contents displayed on the VGA/LCD
are the same as those displayed on the
ultrasound system displayer, no character
and image loss, no color difference, no
fluttering and flicking.
 Smooth communication.
 USB port data storage/accessing are
normal.
5.4 Function Checking
NOTE:
A complete function inspection is described here, do the checking according to the actual
system configuration.
