NV8500 family Digital Routers • User’s Guide 107
6. Technical Details
This section provides technical specifications for the NV8500 family of routers and the NV8000
power supply.
Power Specifications (NV8000, PS8100)
For the NV8280, NV8280-Plus, NV8576, and NV8576-Plus power is supplied through a separate
frame, the NV8000 Power Supply. The following table provides power specifications for the
NV8000 for powering the Routers:
Type Parameters
AC input 90–130/180–250 VAC, 50/60 Hz, automatic ranging
AC fuses No user serviceable fuses
AC connectors 4, IEC 320 (one for each PS8100 module installed)
AC power PS8100, 850 Watts, one IEC 320
AC power usage Power based on PS8100 modules:
NV8144: 1000 Watts nominal (144×144), power factor corrected.
NV8280, NV8280-Plus: 1750 Watts nominal (288×576, 288×288
Expandable), power factor corrected.
NV8576, NV8576-Plus: 3500 Watts nominal (576×1152, 576×576
Expandable), power factor corrected (Each frame requires two NV8000
frames).
Modules and module slots NV8144, NV8280, NV8280-Plus:
Required minimum number of PS8100 modules:
2 primary (2 optional redundant).
NV8576, NV8576-Plus:
Required minimum number of PS8100 modules:
4 primary (4 optional redundant).
Dimensions 3RUs high (5.22 inches, 132.6mm)
19.0″ (482.6 mm) wide.
17.5″ (444.5 mm) deep, approximately. Add 3″ for cable clearance.
Weight 24 lbs (10.9 kg); 50 lbs (22.7 kg) fully loaded
DC power NVISION connector to NV8000, DC cable: WC0096
Power supply alarm
connection
DE9; reads each PS8100 status
Power supply monitor
connection
DB25, loop-through possible
Environmental Operating temperature: 0–40° C
Relative humidity: 0 to 90%, non-condensing
Regulatory compliance UL listed and CE compliant
