NV8500 family Digital Routers • User’s Guide 115
7. Part Numbers
This appendix provides a list of parts provided by Miranda for the NV8500 family of routers, the
NV8000 power supply frame and power supply modules. Unless otherwise noted, part numbers
apply to all routers in the NV8500 family.
Table 7-1. Power Supply
Table 7-2. Frame Expansion
Table 7-3. Input Cards and Backplanes
Table 7-4. Output Cards and Backplanes
Part Number Description
PS8100 Power supply module (850 Watts)
WC0046-00 Power supply monitor cable
WC0096-00 Power supply cable
Part Number Description
WC0121 Expansion cable (4 meters)
WC0084 Terminator
Input Card
Part Number
Signal
Types
Standard Rates
Corresponding
Backplane
EM0687 Asynchronous
digital audio,
unbalanced
AES3 Sample rates 32 kHz to 96 kHz
(passed through)
EM0791 (coax)
EM0687 Asynchronous
digital audio,
balanced
AES3 Sample rates 32 kHz to 96 kHz
(passed through)
EM0828 (WECO)
EM0689 (coax) SD 259M Video rates from 19 Mb/s to 360 Mb/s.
Automatic reclocking at 270 Mb/s.
Reclocking bypassed at other rates.
EM0791 (coax)
EM0783 (coax) 3Gig, HD, SD 259M
344M
292M
424M
Video rates from 19 Mb/s to 3 Gb/s.
Automatic reclocking at 270 Mb/s and
1.483, 1.485, 2.966, 2.970 Gb/s.
Reclocking bypassed at other rates.
EM0791 (coax)
EM0693 (fiber
optic)
EM0696 (fiber
optic)
Output Card
Part Number
Category
Signal
Types
Standard Rates
Corresponding
Backplane
AES Asynchronous Signals (Unbalanced and Balanced)
EM0688 Standalone Unbalanced AES3 Audio sample rates 32
kHz to
96
kHz (passed through)
EM0793
(18 coax)
EM0688 Expansion EM0789 (9 coax,
2 expansion)
EM0688 Filler EM0789 (9 coax,
2 expansion)
To Next Page
