48 Rev 2.2 • 27 Mar 10
2. Installation
Package Contents
Package Contents
When your NV8500 family products from Miranda arrive, immediately inspect the shipping con-
tainer for any obvious damage. If the container is damaged, unpack and inspect the contents. If the
contents are damaged, notify the carrier immediately.
When unpacking the shipping container, look for the packing slip and compare it against the con-
tents to verify that everything ordered was received. If anything is missing (or if equipment is dam-
aged unrelated to shipping), please contact Miranda technical support. See Technical Support
Contact Information on page iii.
The package does not contain mounting rack, network cables, video cables, mounting screws, or
grounding wire.
This document does not address the shipment or installation of any other equipment or software
that can be used in conjunction with the routers, including control systems or configuration soft-
ware.
Preparing for Installation
You will need the following items before getting started:
Depending on the nature of your usage, you will also need an assortment of video cables, video
sources, video monitors, and tools. WECO cables are provided for WECO connectors.
Note
The NV8280/NV8280-Plus and the NV8576/NV8576-Plus use a separate power
supply frame, the NV8000.
A PC running Windows
®
2000 or higher, or Windows XP Professional.
®
This PC is
required for system configuration.
PC hardware requirements:
CD drive.
EIA-232 serial COM port (DE9) capable of operating at 38.4kbps.
10BaseT or 10/100BaseT (preferred) Ethernet port.
100 MB/s Ethernet switch with at least 4 ports.
Ethernet cables (category 5) with RJ-45 connectors.
EIA-232 serial cable with DE9 connectors, wired straight-through, male to female.
Coaxial cable and 75
Ω BNC connectors.
Belden 1855a, or equivalent, cable and DIN 1.0/2.3 connectors and/or LC connectors
and fiber optic cable.
Reference video source (BNC) at the line rate appropriate for your system.
(Optional) Tool for connecting DIN 1.0/2.3 connectors.
Frame rack suitable for mounting the router.
