110 Rev 2.2 • 27 Mar 10
6. Technical Details
Environmental Specifications
Environmental Specifications
The following table provides environmental specifications for all routers:
Output signal monitor Type Standard definition and high definition digital video
Standard See related section of this specification for standard
for each monitored signal type.
Connector DIN 1.0/2.3
Impedance 75 ohms
Signal details See related section of this specification for details
for each monitored signal type, I/O levels, and
return loss.
I/O expansion NV8280-Plus:
Type Proprietary
Standard See related section of this specification for standard
for each signal type sent between routers.
Connector 64, proprietary
Signal Details See related section of this specification for details
for each monitored signal type, I/O levels, and
return loss.
NV8576-Plus:
Type Proprietary
Standard See related section of this specification for standard
for each signal type sent between routers.
Connector 128, proprietary
Signal Details See related section of this specification for details
for each monitored signal type, I/O levels, and
return loss.
Control expansion Type 10Base2 port
Connector 2, BNC, loop-through
Impedance 50
Redundant crosspoint
control
NV8144:
Connector DB25
Redundant crosspoint
card set (2 cards
combined)
NV8280, NV8280-Plus, NV8576, NV8576-Plus:
No connector Internal
Power supply monitor Connector DB25
Type Parameter
Operating temperature 0–40° C
Relative humidity 0 to 90%, non-condensing
