112 Rev 2.2 • 27 Mar 10
6. Technical Details
Video Specifications
Video Specifications
The following table provides video specifications:
Video Reference
SD Inputs and Outputs
3Gig (3.0 Gb/s, HD and SD) Inputs/Outputs
Parameter Specification
Type Analog video reference
Standard PAL, NTSC or tri-Level sync
Connector Loop-through, BNC
Impedance 75 ohms or Hi-Z ( > 20 kΩ), not selectable
Input Level 0.5 V pp to 2.0 V pp
Input Return Loss >30 dB to 5 MHz
Parameter Specification
Type Standard definition serial digital video
Standard SMPTE 259M
Data rates Automatic re-clocking at 270 Mb/s or auto bypass with pass-through from
19 Mb/s to 360 Mb/s
Connector DIN1.0/2.3
Impedance 75 ohms
Cable equalization 350 m Belden 169A, 200 m Belden 1855A, or equivalent cable, at 270 Mb/s
Router path Non-inverting
Input and output return loss > 15 dB, 5 to 540 MHz
Output level 800 mV pp ± 10%
Output rise/fall time 600 ps ± 10%
Output overshoot ≤ 10% of amplitude max
Output alignment jitter ≤ 0.2 UI pp from 1.0 kHz to 27 MHz
Output timing jitter ≤ 0.2 UI pp from 10 Hz to 1.0 kHz
Parameter Specification
Type High definition serial digital video
Standard SMPTE 259M, 292M and 424M
Data rates Automatic re-clocking at 270 Mb/s and 1.483, 1.485, 2.967, 2.970 Gb/s or
automatic bypass with pass-through from 19 Mb/s to 3.0 Gb/s
Connector DIN1.0/2.3
Impedance 75 ohms
