NV8500 family Digital Routers • User’s Guide 111
6. Technical Details
Audio Specifications
Audio Specifications
The following table provides audio specifications:
Type Parameter
Audio reference input Type Serial digital audio
Standard AES3id
Sample rate 48 kHz
Connector 2, BNC (redundant)
Impedance 75 ohms
Input level 0.5 V pp to 2.0 V pp
AES3 inputs/outputs Type Balanced digital audio
Standard AES3
Sample rate Synchronous 48 kHz.
Asynchronous 32 kHz to 192 kHz
Connector WECO
Impedance 110 ohms
Input level 200 mV to 10 Vpp
Output level 2 Vpp
AES3id inputs/outputs Type Unbalanced digital audio
Standard AES3id
Sample rate Synchronous 48 kHz.
Asynchronous 32 kHz to 192 kHz
Connector DIN 1.0/2.3
Impedance 75 ohms
Input level 100 mV to 1.2 V pp
Output level 1 V± 10%
