5. PARAMETERS
5.1 Parameter List
5 PARAMETERS
This chapter explains the function setting for use of this product.
Always read this instructions before use.
The following marks are used to indicate the controls as below. (Parameters without any mark are valid for all control.)
The setting range and the initial value of parameters differ depending on the structure or functions of the inverter. The following
common designations are used for each type of the inverter models.
5.1 Parameter List
5.1.1 Parameter list (by parameter number)
For simple variable-speed operation of the inverter, the initial value of the parameters may be used as they are. Set the
necessary parameters to meet the load and operational specifications. Parameter setting, change and check can be made from
the operation panel.
• indicates simple mode parameters. Use Pr.160 User group read selection to indicate the simple mode
parameters only.
• Parameter setting may be restricted in some operating status. Use Pr.77 Parameter write selection to change the setting.
• Refer to page 623 for instruction codes for communication and availability of parameter clear, all clear, and parameter copy
of each parameter.
Mark Control method Applied motor
V/F control Three-phase induction motor
Advanced magnetic flux vector control
PM sensorless vector control IPM motor
Inverter model Common designation
FR-F860 Standard model
FR-F862 Separated converter type
Magnetic fluxMagnetic fluxMagnetic flux
Simple
Simple
