5.6 (D) Operation command and frequency command
5.6.1 Operation mode selection
Select the operation mode of the inverter.
The mode can be changed among operations using external signals (External operation), operation by operation panel or the
parameter unit (PU operation), combined operation of PU operation and External operation (External/PU combined operation),
and Network operation (when RS-485 terminals or communication option is used).
The following table lists valid and invalid commands in each operation mode.
*1 The priority of frequency commands when Pr.79 = "3" is "multi-speed operation (RL/RM/RH/REX) > PID control (X14) > terminal 4 analog input
(AU) > digital input by operation panel".
Pr. Name Initial value Setting range Description
79
D000
Operation mode selection 0 0 to 4, 6, 7 Selects the operation mode.
Pr.79
setting
Description Operation panel display Refer to
page
0
(initial
value)
External/PU switchover mode.
The inverter operation mode can be switched between PU and External by pressing
.
At power ON, the inverter is in the External operation mode.
PU operation mode
[PU]
External operation mode
[EXT]
NET operation mode
[NET]
208
Operation mode Frequency command Start command
1 PU operation mode fixed Operation panel or
parameter unit.
or on
operation panel or
parameter unit
PU operation mode
[PU]
208
2 External operation mode
fixed.
The operation can be
performed by switching
between the External and
NET operation modes.
External signal input
(terminal 2 and 4, JOG,
multi-speed selection, etc.)
External signal input
(terminal STF, STR)
External operation mode
[EXT]
NET operation mode
[NET]
208
3 External/PU combined
operation mode 1
Operation panel/parameter
unit or external signal input
(multi-speed setting,
terminal 4)
*1
External signal input
(terminal STF, STR)
External/PU combined
operation mode
[PU+E]
209
4 External/PU combined
operation mode 2
External signal input
(terminal 2 and 4, JOG,
multi-speed selection, etc.)
or on
operation panel or
parameter unit
209
6 Switchover mode
Switching of PU, External, and NET operation modes can be performed during
operation.
PU operation mode
[PU]
External operation mode
[EXT]
NET operation mode
[NET]
209
7 External operation mode (PU operation interlock)
X12 signal ON: Switchover to PU operation mode enabled (during External operation,
output shutoff)
X12 signal OFF: Switchover to PU operation mode disabled
210
