Mitsubishi Electric FR-F800 User Manual

343
5. PARAMETERS
5.9 (T) Multi-Function Input Terminal Parameters
3
4
5
5
5
6
7
8
9
10
5.9.8 Input terminal function selection
Use the following parameters to select or change the input terminal functions.
*1 The initial value is for standard models.
*2 The initial value is for separated converter types.
 Input terminal function assignment
• Using Pr.178 to Pr.189, set the functions of the input terminals
• Refer to the following table and set the parameters.
Pr. Name Initial value Initial signal Setting range
178
T700
STF terminal function
selection
60 STF (Forward rotation command) 0 to 8, 10 to 14, 16, 18, 24, 25, 28,
33, 37 to 40, 46 to 48, 50, 51, 57,
58, 60, 62, 64 to 67, 70 to 73, 77
to 81, 84, 92, 94 to 98, 128, 129,
9999
179
T701
STR terminal function
selection
61 STR (Reverse rotation command) 0 to 8, 10 to 14, 16, 18, 24, 25, 28,
33, 37 to 40, 46 to 48, 50, 51, 57,
58, 61, 62, 64 to 67, 70 to 73, 77
to 81, 84, 92, 94 to 98, 128, 129,
9999
180
T702
RL terminal function
selection
0 RL (Low-speed operation command) 0 to 8, 10 to 14, 16, 18, 24, 25, 28,
33, 37 to 40, 46 to 48, 50, 51, 57,
58, 62, 64 to 67, 70 to 73, 77 to 81,
84, 92, 94 to 98, 128, 129, 9999
181
T703
RM terminal function
selection
1 RM (Middle-speed operation command)
182
T704
RH terminal function
selection
2 RH (High-speed operation command)
183
T705
RT terminal function
selection
3 RT (Second function selection)
184
T706
AU terminal function
selection
4 AU (Terminal 4 input selection)
185
T707
JOG terminal function
selection
5 JOG (Jog operation selection)
186
T708
CS terminal function
selection
9999 No function
187
T709
MRS terminal function
selection
24
*1
MRS (Output stop)
10
*2
X10 (Inverter run enable signal)
188
T710
STOP terminal function
selection
25 STP (STOP) (Start self-holding
selection)
189
T711
RES terminal function
selection
62 RES (Inverter reset)
Pr. Name Initial value Setting range Description
699
T740
Input terminal filter 9999 5 to 50 ms Set the time to delay the input terminal response.
9999 No input terminal filter
Setting Signal
name
Function Related parameter Refer to
page
0RLPr.59 = 0 (initial value) Low-speed operation command Pr.4 to Pr.6, Pr.24 to Pr.27, Pr.232 to
Pr.239
226
Pr.59  0
*1
Remote setting (setting clear) Pr.59 197
1RMPr.59 = 0 (initial value) Middle-speed operation command Pr.4 to Pr.6, Pr.24 to Pr.27, Pr.232 to
Pr.239
226
Pr.59  0
*1
Remote setting (deceleration) Pr.59 197
2RHPr.59 = 0 (initial value) High-speed operation command Pr.4 to Pr.6, Pr.24 to Pr.27, Pr.232 to
Pr.239
226
Pr.59  0
*1
Remote setting (acceleration) Pr.59 197
3 RT Second function selection Pr.44 to Pr.51, Pr.450 to Pr.463, Pr.569,
Pr.832, etc.
348
4 AU Terminal 4 input selection Pr.267 318
5 JOG Jog operation selection Pr.15, Pr.16 224
