24
2. INSTALLATION AND WIRING
2.1 Peripheral devices
2 INSTALLATION AND WIRING
This chapter explains the installation and the wiring of this product.
Always read the instructions before using the equipment.
For the INSTALLATION AND WIRING of the separated converter type, refer to the FR-F862 (Separated Converter Type)
Instruction Manual (Hardware).
2.1 Peripheral devices
2.1.1 Inverter and peripheral devices
Earth (Ground)
R/L1 S/L2 T/L3
P1P/+
: Install these options as required.
UVW
IM connection
PM connection
(c) Molded case circuit
breaker (MCCB) or
earth leakage current
breaker (ELB), fuse
(e) AC reactor (f) DC reactor
(i) Noise filter
UVW
(k) Contactor
Example) No-fuse
switch
(DSN type)
(l) PM motor
(g) Noise filter
(d) Magnetic contactor (MC)
(a) Inverter
(b) Three-phase AC power supply
(h) USB connector
USB host
(A connector)
USB device
(Mini B connector)
Communication
status indicator
(LED)(USB host)
Earth
(Ground)
Earth
(Ground)
USB
Personal computer
(FR Configurator2)
(j) Induction
motor
Earth (Ground)
Earth (Ground)
To Next Page
