170
5. PARAMETERS
5.4 (E) Environment setting parameters
5.4.10 Password function
Registering a 4-digit password can restrict parameter reading/writing.
The above parameters can be set when Pr.160 User group read selection = "0". However, when Pr.296 9999 (password
lock is set), Pr.297 can always be set, regardless of the setting in Pr.160.
*1 When Pr.297 = "0, 9999", writing is always enabled, but setting is disabled. (The display cannot be changed.)
Parameter reading/writing restriction level (Pr.296)
• The level of the reading/writing restriction using the PU/Network (NET) operation mode operation command can be
selected with Pr.296.
: Enabled, : Disabled
*1 If the parameter reading is restricted by the Pr.160 User group read selection setting, those parameters are unavailable for reading even when
"" is indicated.
*2 If the parameter writing is restricted by the Pr.77 Parameter write selection setting, those parameters are unavailable for writing even when ""
is indicated.
*3 This restricts parameter access from the command source that can write a parameter under the PU operation mode (initially the operation panel
or the parameter unit). (For the PU operation mode command source selection, refer to page 214.)
*4 This restricts parameter access from the command source that can write a parameter under the Network operation mode (initially the RS-485
terminals or a communication option). (For the NET operation mode command source selection, refer to page 214.)
*5 Read/write is enabled only for the simple mode parameters registered in the user group when Pr.160 = "9999". Pr.296 and Pr.297 are always
read/write enabled whether registered to a user group or not.
*6 If a communication option is installed, an option fault Option fault (E.OPT) occurs, and the inverter output shuts off. (Refer to page 580.)
*7 The PLC function user parameters (Pr.1150 to Pr.1199) can be written and read by the PLC function regardless of the Pr.296 setting.
Pr. Name Initial value Setting range Description
296
E410
Password lock level 9999 0 to 6, 99, 100 to
106, 199
Select restriction level of parameter reading/
writing when a password is registered.
9999 No password lock
297
E411
Password lock/unlock 9999 1000 to 9998 Register a 4-digit password
(0 to 5)
*1
Displays password unlock error count. (Reading
only) (Valid when Pr.296 = "100 to 106, or 199")
9999
*1
No password lock
Pr.296 setting PU operation mode operation
command
*3
NET operation mode operation command
*4
RS-485 terminals / PLC function
*7
Communication option
Read
*1
Write
*2
Read Write
*2
Read Write
*2
9999
0, 100
*6
1, 101
2, 102
3, 103
4, 104
5, 105
6, 106
99 to 199
Only the parameters registered in the user group can be read/written.
*5
(For the parameters not registered in the user group, same restriction level as "4, 104" applies.)
