6. PROTECTIVE FUNCTIONS
6.3 The list of fault displays
6.3 The list of fault displays
If the displayed message does not correspond to any of the
following or if you have any other problem, please contact
your sales representative.
 Error message
• A message regarding operational fault and setting fault
by the operation panel and the parameter unit is
displayed. The inverter does not trip.
 Warning
• The inverter does not trip even when a warning is
displayed. However, failure to take appropriate measures
will lead to a fault.
 Alarm
• The inverter does not trip. An Alarm (LF) signal can also
be output with a parameter setting.
 Fault
• A protective function trips the inverter and outputs a Fault
(ALM) signal.
• The data code is used for checking the fault detail via
communication or with Pr.997 Fault initiation.
Abbreviation Name Refer
to
LOCD Password locked 570
Er1 to Er 4
Er8
Parameter write error 570
rE1 to rE8 Copy operation error 571
Err. Error 572
Abbreviation Name Refer
to
page
OL Stall prevention (overcurrent) 573
oL Stall prevention (overvoltage) 573
TH Electronic thermal relay function pre-
alarm
573
PS PU stop 574
CP Parameter copy 574
SA Safety stop 574
MT1 to MT3 Maintenance signal output 574
UF USB host error 574
CF Continuous operation during
communication fault
574
ED Emergency drive in operation 574
LDF Load fault warning 575
Abbreviation Name Refer
to
page
FN Fan alarm 575
Abbreviation Name Data
code
Refer
to
page
E.OC1 Overcurrent trip during
acceleration
16
(H10)
575
E.OC2 Overcurrent trip during
constant speed
17
(H11)
576
E.OC3 Overcurrent trip during
deceleration or stop
18
(H12)
576
E.SCF Output short-circuit fault 20
(H14)
576
E.OV1 Regenerative overvoltage trip
during acceleration
32
(H20)
576
E.OV2 Regenerative overvoltage trip
during constant speed
33
(H21)
577
E.OV3 Regenerative overvoltage trip
during deceleration or stop
34
(H22)
577
E.THT Inverter overload trip
(electronic thermal relay
function)
48
(H30)
577
E.THM Motor overload trip (electronic
thermal relay function)
49
(H31)
577
E.FIN Heat sink overheat 64
(H40)
578
E.IPF Instantaneous power failure 80
(H50)
578
E.UVT Undervoltage 81
(H51)
578
E.ILF Input phase loss 82
(H52)
578
E.OLT Stall prevention stop 96
(H60)
579
E.SOT Loss of synchronism detection 97
(H61)
579
E.LUP Upper limit fault detection 98
(H62)
579
E.LDN Lower limit fault detection 99
(H63)
579
E.BE Internal circuit fault 112
(H70)
583
E.GF Output side earth (ground)
fault overcurrent
128
(H80)
579
E.LF Output phase loss 129
(H81)
580
E.OHT External thermal relay
operation
144
(H90)
580
E.PTC PTC thermistor operation 145
(H91)
580
E.OPT Option fault 160
(HA0)
580
E.OP1 Communication option fault 161
(HA1)
580
