553
5. PARAMETERS
5.13 (G) Control parameters
3
4
5
5
5
6
7
8
9
10
5.13.10 DC feeding mode
• It is possible to choose between the DC feeding mode 1, which will operate with DC power supply (terminals P and N), and
DC feeding mode 2, which will normally operate in AC power supply (terminals R, S, and T) and operate in DC power
supply (terminal P and N), such as batteries, at the time of power failure.
• While the power is supplied only to the control circuit, the reset operation when the power is supplied to the main circuit
can be selected.
*1 The initial value or setting range for the standard model
*2 The initial value or setting range for the separated converter type.
Details of the setting value
• FR-F862-05450 or higher
*1 While the power is supplied only to the control circuit with Pr.30 = "100 or higher", the inverter reset is not performed when the power is supplied
to the main circuit.
Pr. Name Initial
value
Setting range Description
30
E300
Regenerative function
selection
0
*1
10
*2
0, 10, 20, 100,
110, 120
*1
Select the value according to the terminals used for power supply
and whether to reset the inverter when the power is supplied to the
main circuit.
10, 110
*2
1, 2, 11, 21, 101,
102, 111, 121
For manufacturer setting. Do not set.
599
T721
X10 terminal input
selection
0
*1
1
*2
0 Normally open input
1 Normally closed input (NC contact input specification)
Power supply terminals of inverter Pr.30 Setting
*1
R, S, T 0 (initial value), 100
P, N 10, 110
R, S, T/P, N 20, 120
For manufacturer setting. Do not set. 1, 2, 11, 21, 101, 102, 111, 121
Regeneration unit Pr.30 Setting
*1
Without regenerative function (FR-CC2-C) 10 (initial value), 110
For manufacturer setting. Do not set. 2, 11, 102, 111
