8. SPECIFICATIONS
8.3 Outline dimension drawings
3
4
5
5
5
5
5
8
9
10
8.3 Outline dimension drawings
8.3.1 Inverter outline dimension drawings
FR-F860-00027, 00061, 00090
*1 FR-F860-00027 is not provided with a cooling fan.
(Unit: mm)
2×6 hole
45.5
5
140
245
(7.5)
260
6
12.5
150
125
7.5
(12.5)
(58)
84.5
28 47 47 (28)
3×35 hole
(With a knockout hole)
318(2.3)
FAN
*1
