Motorola iDEN Site Controller User Manual

Chapter 4 Installation Gen 3 Site Controller System Manual
Intercabling Connections
4-44 68P80801E30-A 5/1/2002
Table 4-18 System Alarm Inputs
Alarm Code P10 (SYSTEM ALARM / CONTROL) Pin No. Function
EAS (D-SUB 50 CONN.) EAS2 (CHAMP 50 CONN.)
RETURN
Signal (Live)
Connection
RETURN
Signal (Live)
Connection
210 6 5 23 48 reserved for system use
224 8 7 22 47 reserved for system use
241 10 9 21 46 reserved for system use
249 12 11 20 45 reserved for system use
250 14 13 19 44 reserved for system use
251 16 15 18 43 reserved for system use
247 18 17 17 42 major rectifier failure
246 20 19 16 41 minor rectifier module
failure
245 22 21 15 40 breaker failure alarm
244 24 23 14 39 high DC voltage
243 26 25 13 38 low DC voltage
242 28 27 12 37 AC Power failure
223 30 29 11 36 predefined input, site AC
surge protector
222 32 31 10 35 predefined input, site smoke
detector
221 34 33 9 34 predefined input, site low
ambient temperature
220 36 35 8 33 predefined input, site high
ambient temperature
219 38 37 7 32 predefined input, site entry
