68P80801E30-A 5/1/2002 6-27
Gen 3 Site Controller System Manual Chapter 6 System Testing
EAS/EAS2 Alarm Checkout
Note: The tower top amplifier response (codes 228, 232, and 236) to the
display eas command is only returned on systems containing a
cavity combining RF Distribution System.
2. To verify a particular alarm, perform the proper action to trigger it.
For example, the following describes this verification.
2.1 Open the site entry door.
2.2 Type: display eas
The status of the Site Entry alarm (code 219) changes to the
alarm state.
2.3 Close the site door.
2.4 Type: display eas
The Site Entry alarm (code 219) returns the O.K. condition.
3. Verify other alarms for proper wiring by triggering them as described
above.
Some actions trigger more than one alarm. For instance, switching off the
main breaker to the Controller. Other alarms are site-specific, and may or
may not be wired. Site-specific alarms are generally more difficult to trigger
manually.
The alarm actions listed below do not remove power from the controller.
Removing controller power disrupts the testing procedure.
A list of alarms and actions required to trigger each are given in Table 6-4.
Table 6-4 Alarm action and alarm responses
If you do this . . . Then this alarm triggers . . .
Open site entry door Site entry
Set off smoke alarm Site smoke detector
Trip thermostat high point Site high ambient temperature
Trip thermostat low point Site low ambient temperature
Switch off the EAS breaker Control equipment cabinet circuit
breaker alarm
Switch off the RFS1 breaker of RFC1 RFC 1 circuit breaker and combiner/
multicoupler power supply
