Motorola iDEN Site Controller User Manual

68P80801E30-A 5/1/2002 4-11
Gen 3 Site Controller System Manual Chapter 4 Installation
Intercabling Connections
16-20 Channel Cavity Omni Site Cables
Table 4-4 lists the required cables for a 16-20 channel cavity omni site.
Table 4-4 16-20 Channel Cavity Omni Site Intercabling
Cable PN Description Qty. Connections
0112004Z29 Ethernet 4 Site controller to Main RF Cabinet
Main RF Cabinet to Expansion RF
Cabinet #1
Expansion RF Cabinet #1 to
Expansion RF Cabinet #2
Expansion RF Cabinet #2 to
Expansion RF Cabinet #3
0112004Z29 5 MHz/1 PPS 4
Site controller to Main RF Cabinet
Main RF Cabinet to Expansion RF
Cabinet #1
Expansion RF Cabinet #1 to
Expansion RF Cabinet #2
Expansion RF Cabinet #2 to
Expansion RF Cabinet #3
3084225N42 Alarms 4 Control Cabinet to Main RF Cabinet
Control Cabinet to Expansion RF
Cabinet #1
Control Cabinet to Expansion RF
Cabinet #2
Control Cabinet to Expansion RF
Cabinet #3
0182004W04 Phasing Harness 2 Main RF Cabinet/Expansion RF
Cabinet #1
Expansion RF Cabinet #2/Expansion
RF Cabinet #3
0112004B24 Receive
Expansion Cables
9 Main RF Cabinet to Expansion RF
Cabinets
