Motorola iDEN Site Controller User Manual

Chapter 4 Installation Gen 3 Site Controller System Manual
Intercabling Connections
4-10 68P80801E30-A 5/1/2002
11-15 Channel Cavity Omni Site Cables
Table 4-3 lists the required cables for an 11-15 channel cavity omni site.
Table 4-3 11-15 Channel Cavity Omni Site Intercabling
Cable PN Description Qty. Connections
0112004Z29 Ethernet 3 Site controller to Main RF Cabinet
Main RF Cabinet to Expansion RF
Cabinet #1
Expansion RF Cabinet #1 to
Expansion RF Cabinet #2
0112004Z29 5 MHz/1 PPS 3 Site controller to Main RF Cabinet
Main RF Cabinet to Expansion RF
Cabinet #1
Expansion RF Cabinet #1 to
Expansion RF Cabinet #2
3084225N42 Alarms 3 Control Cabinet to Main RF Cabinet
Control Cabinet to Expansion RF
Cabinet #1
Control Cabinet to Expansion RF
Cabinet #2
0182004W04 Phasing Harness 1 Main RF Cabinet/Expansion RF
Cabinet #1
0112004B24 Receive
Expansion Cables
6 Main RF Cabinet to Expansion RF
Cabinet
