68P80801E30-A 5/1/2002 9-7
Gen 3 Site Controller System Manual Chapter 9 Controller
Controller
Performance Specifications
Table 9-5 lists the specifications.
Table 9-5 Controller performance specifications
Specifications Value or range
Input supply voltage range -40 to 60 VDC
Power Consumption 30W typical;
40W maximum
Operating temperature -30˚ to 60˚ C
Storage temperature -40˚ to 185˚ F (-40˚ to 85˚ C)
Humidity 75% R.H. at 55˚ C (Max.)
