Appendix B Parts & Suppliers Gen 3 Site Controller System Manual
B-16 68P80801E30-A 5/1/2002
For a standard configuration, the equipment cabinets are located adjacent to
the Power Supply Rack with a cable loop length less than 35’.
Each equipment cabinet has a total of four Power Supply Rack connections:
two -48 Vdc (hot) and two DC returns. Each equipment cabinet contains two
separate power distribution systems. A single hot wire and a single return
wire are used for each side of the bus. Two return leads provide redundancy
and allow a uniform wire size to be used for all 48 Vdc power distribution
system connections.
Other recommended suppliers
The following are the addresses of various suppliers for equipment used
during system installation.
Test Equipment
■ Fluke 77 Digital Multimeter
Fluke Corporation
P.O. Box 9090
Everett, WA 98206-9090
Phone: 425-347-6100
Internet: www.fluke.com
Table B-11 Power connection wire size
Loop length Wire size
25 feet or less #6 AWG
25 to 40 feet #4 AWG
40 to 60 feet #2 AWG
60 to 130 feet 1/0 AWG
NOTE: The wire sizes listed are large enough to
allow expansion of an RF Cabinet to five Base
Radios.
Table B-12 Power connection wire size for Cabinets
Loop length Wire size
150 feet or less #6 AWG
