Motorola iDEN Site Controller User Manual

Chapter 4 Installation Gen 3 Site Controller System Manual
Intercabling Connections
4-12 68P80801E30-A 5/1/2002
Sectored Site Cables
Table 4-5 lists the required cables for a three sectored site.
800 MHz Duplexed RFDS Intercabinet Cabling
Intercabling between the Control Cabinet and the RF Cabinets for systems
equipped with Duplexed RF Distribution Systems is listed below. Choose
the appropriate table below, then refer to the appropriate instructions for
connecting the required intercabling.
1-4 Channel Omni Site Cables
Table 4-6 lists the required cables for an omni site (single sector).
Table 4-5 Sectored Site Intercabling
Cable PN Description Qty. Connection
0112004Z29 Ethernet 1 Site controller to RF Cabinet #1
0112004Z29 Ethernet 1 RF Cabinet #1 to RF Cabinet #2
0112004Z29 Ethernet 1 RF Cabinet #2 to RF Cabinet #3
0112004Z29 5 MHz/1 PPS 1
Site controller to RF Cabinet #1
0112004Z29 5 MHz/1 PPS 1 RF Cabinet #1 to RF Cabinet #2
0112004Z29 5 MHz/1 PPS 1 RF Cabinet #2 to RF Cabinet #3
3084225N42 Alarms 1 EAS/EAS2 to RF Cabinet #1
3084225N42 Alarms 1 EAS/EAS2 to RF Cabinet #2
3084225N42 Alarms 1 EAS/EAS2 to RF Cabinet #3
3082070X01 PCCH
Redundancy
1
Site controller to RF Cabinet #1
Site controller to RF Cabinet # 2
Site controller to RF Cabinet #3
Table 4-6 1-4 Channel Omni Site Intercabling
Cable PN Description Qty. Connection
0112004Z29 Ethernet 1 Site controller to RF Cabinet #1
0112004Z29 5 MHz/1 PPS 1 Site controller to RF Cabinet #1
3084225N42 Alarms 1 EAS/EAS2 to RF Cabinet #1
